| Engine Type: |
Single cylinder,wind-cooled, four stroke |
| Displacement: |
110cc |
| Compression Ratio: |
9.3:1 |
| Max. Power(kw/r/min) |
5.8/8000 |
| Max. Torque (N.m/r/min): |
7.64/5500 |
| Max. Speed (Km/h): |
≥106 |
| Lubrication: |
Pressure ,splash |
| Clutch Type: |
Multiplate wet clutch, Automatic |
| Ignition: |
CDI |
| Starting System: |
E-start |
| Transmission System: |
Chain drive |
| The left and right steering angle |
L42º R41º |
| Front Brake: |
Disc brake |
| Rear Brake: |
Drum brake |
| Front Tire: |
70/90-17 |
| Rear Tire: |
80/90-17 |
| Battery: |
12V/5Ah |
| Seat Height(mm): |
770 |
| Wheelbase(mm): |
1280 |
| Min. Ground Clearance(mm): |
160 |
| Max. Permissionable Weight(kg): |
150 |
| Rider Capacity: |
1 Person |
| Dry. Weigth(kg): |
83 |
| Fuel Tank Capacity(L): |
4.2L |
| Roll angle |
11º |
|
